Coil Winder Resume Samples

A Coil Winder winds coils that are used typically in electrical equipment and instruments or electronic components. The job description and duties are listed on the Coil Winder Resume as – reviewing wiring diagrams and work order; examining sample coil for ascertaining type and size of the wire specified; selecting coil-forming device; threading ends of the wire from reel; turning setscrews to adjust the tension on wire and sets; starting the machine and manually feeding wire over coil core; wrapping insulation between layers; cutting wire to form leads, and observing counter and stopping machine at a specified number of coils.

The most sought-after skills for the post include the following – strong color vision to distinguish different colors of the wires; manual dexterity with a steady hand and good hand-eye coordination; mathematical skills; mechanical skills; and the ability to understand the technical manuals and blueprints. A diploma directly related to the area of work is preferred. However, formal education beyond a high school diploma is not mandatory.

Coil Winder Resume example

Coil Winder Resume

Objective : To obtain a Coil Winder position where my diverse business and technical skills contribute to the success and growth of this organization.

Skills : Forklift, Transformers, Winding.

Description :

    1. Set up winding mandrel adjusting spacers for different size coils.
    2. Loaded one or multiple strip stocks and one insulating paper reels on derailing mechanism and adjust tension rollers on all feeds.
    3. Threaded stock to feed position. Placed coil form on the mandrel, wraps form with paper, positions lead, and tapes to coil form.
    4. Operated machine regulating the winding speed with foot control, aligning aluminum strip to the center of the insulating paper strip, and both to the center of coil form and adjusts tensioning devices as required.
    5. Inserted oil ducts and other special insulating paper and varnish at specified places in the coil.
    6. Cut conductors at the specified turn, welding on leads, taping and insulating to coil body.
    7. Winded "major" insulation and applies varnish and ducts by hand.
    8. Unloaded and stacked coils and records identification data on coils.
Years of Experience
Experience
0-2 Years
Experience Level
Level
Entry Level
Education
Education
Education


Coil Winder Resume

Headline : To have a Coil Winder position where to use my skills and hardworking ability, to benefit employer and be of service to others and increase the productivity of a company.

Skills : Microsoft Excel, Spreadsheet, Computer Add Machines And Marketing.

Description :

    1. Attached, altered, and trimmed materials such as wire, insulation, and coils, using hand tools.
    2. Cut, stripped, and bended wire leads at ends of coils, using pliers and wire scrapers.
    3. Examined and tested wired electrical components such as motors, armatures, and stators, using measuring devices; and record the test results.
    4. Lined slots with sheet insulation, and insert coils into slots.
    5. Operated or tended wire-coiling machines to wind wire coils used in electrical components such as resistors and transformers, and in electrical equipment and instruments such as bobbins and generators.
    6. Reviewed work orders and specifications to determine materials needed and types of parts to be processed.
    7. Selected and loaded materials such as workpieces, objects, and machine parts onto equipment used in coiling processes.
    8. Stopped machines to remove completed components, using hand tools.
    9. Applied solutions or paints to wired electrical components, using hand tools; and bake components.
Years of Experience
Experience
5-7 Years
Experience Level
Level
Executive
Education
Education
A.S In Automotive Technician


Coil Winder Resume

Objective : As a Coil Winder over 3 years responsible to set up and wind medium and large power 1 and 2 wire disc windings, multiple disc windings from 1 to 16 wires, and screw and RV windings.

Skills : Can Read Blueprints And Floor Plans, Skilled Forklift Operator, Customer Service Experience, Forklift Driver, Certified Advanced Manufacturing Skilled.

Description :

    1. Received assignments and instructions from the supervisor.
    2. Assembled material at the workplace, components to the cylinder,
    3. Performed machine and material set up.
    4. Loaded cylinder to the machine. Winded coil as per specs.
    5. Verified accuracy of winding per in-process checklist.
    6. Unloaded and upended coil and position end assembly as required.
    7. Assisted others with their windings,
    8. Performed minor repairs and machine maintenance. Write repair work orders as required.
    9. Repaired coil in any department or work center.
    10. Kept tools, equipment and workplace neat and orderly.
Years of Experience
Experience
2-5 Years
Experience Level
Level
Junior
Education
Education
G.E.D

Coil Winder Resume

Summary : As a Coil Winder performs all types of rewinds on AC/DC motors, performs electrical troubleshooting, preventative maintenance, and field installation of equipment.

Skills : Product Quality, Setup, Transformers.

Description :

    1. Observed and adhered to Industrial Repair safety procedures.
    2. Maintained Industrial Repair quality standards.
    3. Rewinded electric motors, stators and armatures.
    4. Torn down equipment utilizing the manufacturer’s recommendations and industry best practices using necessary tools.
    5. Inspected equipment and parts for damage, diagnose possible reason(s) for failure.
    6. Provided information on parts/work required.
    7. Provided recommendations to improve the reliability of equipment.
    8. Completed information in reports as required.
Years of Experience
Experience
7-10 Years
Experience Level
Level
Management
Education
Education
B.S in Mechanics

Coil Winder Resume

Objective : As a Coil Winder over 5 years responsible to perform the testing, rewind, refurbishment of AC and DC motors. May perform operations involving dismantling, rewinding, repairing, reassembling, and testing motors.

Skills : Inspecting, Repairing, Management, Organizing.

Description :

    1. Operated machinery to wind coils used in electrical equipment and instruments.
    2. Used of measuring devices, (i.e.: ruler, micrometer, vernier, etc.), hand tools, and testing devices (i.e.: megger, voltmeter, etc.).
    3. Understood how to take connections data and develop wiring diagrams.
    4. Relied on limited experience and judgment to plan and accomplish goals.
    5. Cleaned, staged, and checked parts for accuracy.
    6. Helped other team members by assembling parts.
    7. Adjusted and maintained conductor tension in order to meet coil dimension requirements.
Years of Experience
Experience
2-5 Years
Experience Level
Level
Junior
Education
Education
High School In General

Coil Winder Resume

Summary : Seeking an Assembly or Production position in a manufacturing setting that will allow effective organizational abilities and technical skills to be put to the best use.

Skills : Operational Data, Setup, Testing.

Description :

    1. Worked from engineering drawings, specifications, design prints, and manufacturing practices.
    2. Setup winding machines and expandable mandrels.
    3. Brazed copper leads. Transposed conductors.
    4. Winded single and multi-conductor disc, single and double helix, and layer windings including rectangle, barrel, and elliptical forms.
    5. Recognized conductor pressure points and how to insulate these areas.
    6. Built winding bridges and risers used in disc windings.
    7. Referred to manufacturing practices, standard practices, winding prints, and bills of material to interpret and obtain the winding form size, conductor size, turns, layers, tape, glue, insulation and dimensions to name a few key items.
Years of Experience
Experience
10+ Years
Experience Level
Level
Senior
Education
Education
Diploma in Manufacturing

Coil Winder Resume

Headline : To obtain a responsible and challenging Coil Winder position where my education and work experience will have valuable relevance.

Skills : Transformers specifications, Wire Scrapers, Assembly Line.

Description :

    1. Created many different types of coils on multiple coil winder machines to meet the customer's order.
    2. Assembled the parts as well as test the coils to ensure that the quality is still what the customer wants.
    3. Communicated with team members in the coil department to ensure that the customer gets the best quality coils delivered to the next step in the process of creating a heating element.
    4. Used Operating a coil winder machine Communication with other team members in the same department as well as communicating with other departments.
    5. Recognized conductor and winding defects in order to take corrective action including notifying a supervisor as needed.
    6. Repaired coils of any type and size at various stages of manufacture and in certain field situations.
    7. Provided assistance to the supervisor in on-the-job orientation and training of other employees as well as helps out in other work centers on a temporary basis.
Years of Experience
Experience
5-7 Years
Experience Level
Level
Executive
Education
Education
B.S Of Manufacturing

Coil Winder(Electrical) Resume

Summary : Over 8 years of experience as a Coil Winder operate transformer coil winding machines, winding machines for field and stator coils for electric motors, tig weld aluminum wire, solder copper wire with a torch, operate for lift, overhead crane, operate wire taping machine to put Nomex tape on the bare wire, and operate shear.

Skills : Hand Tools, Aluminum, Electric Motors.

Description :

    1. Worked safely and be an advocate for safety.
    2. Cleaned and maintained equipment, tooling, and area.
    3. Assembled motors and generators using a combination of hand, electric, and pneumatic tools.
    4. Responsible for tape measures, gauges, micrometers, and torque wrenches.
    5. Worked independently, holding close tolerances, minimizing scrap all within standard routing hours, and with excellent attention to detail.
    6. Performed setup and operation of mechanical and tooling equipment with limited supervision.
    7. Followed instructions and repeated basic procedures of the Motor Assembly position.
Years of Experience
Experience
7-10 Years
Experience Level
Level
Consultant
Education
Education
B.S in Manufacturing

Coil Winder Resume

Objective : Over 2 years of experience as a Coil Winder responsible to Collect, read, and understand winding data and connections. Familiarity and experience with winding electrical wiring diagrams, insulation materials, brazing techniques, and coil forming.

Skills : Solidworks, Machine Operator, Manufacturing, SAP, Management, Filemaker Pro.

Description :

    1. Identified the type of equipment needing repair such as AC/DC Motors, generators, armatures, transformers, coils, etc.
    2. Documented the external data associated with the equipment or winding.
    3. Diagnosed and/or tested the equipment for malfunctions, failures, or damage using diagnostic equipment such as megger, hi-pot, AC or DC test panels, and related equipment.
    4. Dismantled equipment and collected internal data.
    5. Identified and documented internal winding data. Converted internal winding data as applicable per EASA guidelines.
    6. Removed old winding from core or bobbin.
    7. Utilized available core test equipment and programs to determine core viability and proper heat dispersion.
    8. Repaired or modified existing core to meet test criteria.
    9. Complete full or partial core re-stack, if necessary


Years of Experience
Experience
0-2 Years
Experience Level
Level
Entry Level
Education
Education
AAS In Manufacturing

Coil Winder Resume

Headline : To gain a Coil Winder position with a growing company, that allows me to utilize training and advance in the process.

Skills : Wire Coils, Transformer Units, Inspect machine.

Description :

    1. Built quality magnetic coils for the transformer with a checklist. Kept area clean as possible, reading inside specs, on how coils were to be built as needed.
    2. Made sure the coil was made on or before the time that was needed for production.
    3. Worked with smart thoughts and a safe way throughout the day at work.
    4. Determined correct insulation of core and component parts applicable to the equipment Insulation Classification.
    5. Correctly sized and winded coils or wire applicable to insulated equipment.
    6. Performed appropriate wire insertion, wedging, and tying of winding or wire.
    7. Performed connection sequence including equipment necessary for final soldering, brazing or welding of internal coil leads to exterior leads.
    8. Tied and proofed end clearance of finished winding.
Years of Experience
Experience
5-7 Years
Experience Level
Level
Executive
Education
Education
A.S in Fabrication
